A home made softbox made of scrap

Discussion in 'Beyond the Basics' started by Garbz, Aug 12, 2007.

  1. Garbz

    Garbz No longer a newbie, moving up!

    Joined:
    Oct 26, 2003
    Messages:
    9,713
    Likes Received:
    203
    Location:
    Brisbane, Australia
    Can others edit my Photos:
    Photos NOT OK to edit
    In response to a PM I received I decided to post this here. A quick and simple softbox for a flash and in the true DIY style a typical home will have all of these ingredients laying around somewhere.

    [​IMG]

    The softbox was made out of a shoebox, and had to be small enough for quick hand held usage, hence the 20x20cm size. Yes it is small but every bit helps when making lighting softer. The box is constructed from triangle bits which have been taped together. The inside of the box was covered with glue and lined with shiny aluminium foil. This prevents wasting flash power and I gained more than a full stop in power. It also makes the specular light source wider since this now reflects off the walls. The front is covered with very thin paper. Experimentation is the key here as the paper needs to be thick enough not to let the source light through defeating the diffusing action, yet thin enough not to waste power.

    The end result works remarkably well, cost $0 not including the $100 shoes, and at the expense of between 1-2 stops of light you get a significantly softer source.

    Poorly exposed sample image: http://i12.photobucket.com/albums/a241/Garbz01/junk/DSC_1074-1.jpg Softbox was around 2m to the left. No it's not as good as a studio softbox, but a) it helps, and b) who can argue with the price :)

  2. deanimator

    deanimator TPF Noob!

    Joined:
    Jun 1, 2007
    Messages:
    534
    Likes Received:
    0
    Location:
    East Germany
    Can others edit my Photos:
    Photos NOT OK to edit
    Next up from Garbz will be a snoot made from a Fosters can (pre-emptied!) :)

  3. Pixie42

    Pixie42 TPF Noob!

    Joined:
    Apr 4, 2007
    Messages:
    64
    Likes Received:
    0
    Location:
    Canada
    Can others edit my Photos:
    Photos OK to edit
    That's pretty neat, thanks for sharing.

  4. DeepSpring

    DeepSpring TPF Noob!

    Joined:
    Jul 12, 2006
    Messages:
    1,451
    Likes Received:
    0
    Location:
    Los Angeles
    Can others edit my Photos:
    Photos OK to edit
    Looks good. I made a similar one out of a tupper wear container. I just glued paper to the front and cut a hole in the back that my flash slips into.

    I eventually just got the real foldable mini soft box so i can carry it easily

  5. Jon, The Elder

    Jon, The Elder TPF Noob!

    Joined:
    Jul 10, 2007
    Messages:
    376
    Likes Received:
    0
    Location:
    Southeastern Michigan
    Can others edit my Photos:
    Photos NOT OK to edit
    Nice to see creativity in action. Stuck out in nowhere on a remote....that knowledge and ingenuity could come in handy.

  6. DeadEye

    DeadEye TPF Supporters Supporting Member

    Joined:
    May 16, 2007
    Messages:
    960
    Likes Received:
    11
    Can others edit my Photos:
    Photos OK to edit
    For a few bucks (yea it kills the 0 budget) try a sheet of mylar drafting film matte finish both sides instead of paper.

  7. neea

    neea TPF Noob!

    Joined:
    Nov 27, 2006
    Messages:
    710
    Likes Received:
    0
    Location:
    Canada
    Can others edit my Photos:
    Photos NOT OK to edit
    Neat. I'll have to try my crafty skills at this project.
    Right after I finish my mile long list of other things to build. Backdrop stand, light stand, etc.

  8. gravy

    gravy TPF Noob!

    Joined:
    Mar 25, 2007
    Messages:
    156
    Likes Received:
    0
    Location:
    Edmonton, AB
    Can others edit my Photos:
    Photos NOT OK to edit
    that's awesome! thanks for posting this!

  9. Garbz

    Garbz No longer a newbie, moving up!

    Joined:
    Oct 26, 2003
    Messages:
    9,713
    Likes Received:
    203
    Location:
    Brisbane, Australia
    Can others edit my Photos:
    Photos NOT OK to edit
    Oh just a note on the paper. The paper used here is actually a paper bag, funnily enough the paper bag you get given from a newsagent when you buy sheets of paper :lol:

    Hey just because I live in Australia doesn't mean I have bad taste. It definitely won't be made from a Fosters can :p Speaking of which I don't actually have a snoot. I remember needing one desperately once so I used a rolled up newspaper and a piece of string and had someone hold it for me.

    Seriously I should start up my own home brand photography company called ghetto photography. Along with all of this the only cameras I will allow are Holgas :D

  10. NJMAN

    NJMAN TPF Noob!

    Joined:
    Aug 1, 2006
    Messages:
    2,104
    Likes Received:
    2
    Location:
    Far beyond the bowels of human existence...Minneso
    Can others edit my Photos:
    Photos NOT OK to edit
    Thanks for the great tips on the homemade softbox! Looks quite interesting and fun to build. Thanks for sharing.

    Yes, I am the one who PM'ed Garbz about this in the first place. ;-)

  11. DeadEye

    DeadEye TPF Supporters Supporting Member

    Joined:
    May 16, 2007
    Messages:
    960
    Likes Received:
    11
    Can others edit my Photos:
    Photos OK to edit
    I call this homebrew. In Ham Radio I build about half of my equipment. A lot of the Ham Homebrew is far better than anything you can buy plus you lean a great deal by building.

  12. Big Mike

    Big Mike I am Big, I am Mike Staff Member Supporting Member

    Joined:
    Dec 16, 2003
    Messages:
    33,818
    Likes Received:
    1,811
    Location:
    Edmonton
    Can others edit my Photos:
    Photos NOT OK to edit
    Nicely done.

    I made a flash deflector one time, it worked well but it's not as portable as the store bought models.

    Here it is...
    [​IMG]


    As for a snoot, I've made one with the same 'sheet foam' that I used for the deflector. I just rolled it around the head of the flash and put a rubber band on it.
