Curious Phenomenon

Discussion in 'Beyond the Basics' started by enki9, Jan 25, 2006.

  1. enki9

    enki9 TPF Noob!

    Joined:
    Jan 25, 2006
    Messages:
    5
    Likes Received:
    0
    Back over at another forum there was this helicopter picture posted.
    http://www.airforce.ru/photogallery/dundin/kuznetsov2004/bpk/page_07.htm

    Could anyone explain, Why do two rotor blades seem bent? In reality they are absolutely straight even when in motion. It is a photographic phenomenon, but what causes it? I know something about optics and slow shutter speeds, but this phenomenon puzzles me.

    Other pictures show the moving rotor blades just fuzzy, like you'd rather expect:
    http://www.airforce.ru/photogallery/dundin/kuznetsov2004/bpk/page_12.htm

    (I didn't get the images linked directly, so there are just the links, sorry.)
    Any reasonable explanation out there?

  2. Azuth

    Azuth TPF Noob!

    Joined:
    Dec 25, 2005
    Messages:
    262
    Likes Received:
    2
    Location:
    Sydney 'strailya
  3. markc

    markc TPF Noob!

    Joined:
    Mar 8, 2004
    Messages:
    4,237
    Likes Received:
    6
    Location:
    Rochester, NY Velocity: Unknown
    Can others edit my Photos:
    Photos NOT OK to edit
    Andrew Davidhazy exploits the same effect using a modified Polaroid to get images like this:

    [​IMG]

    The lens is replaced by a vertical slit and a string is run from the film tab to a small motor. When the shutter is pressed, the film is pulled past the slit. I was standing on a turntable rotating in front of the camera.

  4. enki9

    enki9 TPF Noob!

    Joined:
    Jan 25, 2006
    Messages:
    5
    Likes Received:
    0
    Thank you for the replies. I should have thought something like what was explained in the link Azuth posted.

    The moving rotors in the second photograph I linked to are, however, not bent. Is this because a slower shutter speed?

  5. hobbes28

    hobbes28 Incredible Supporting Member

    Joined:
    Jul 10, 2004
    Messages:
    4,807
    Likes Received:
    41
    Location:
    at work...
    There's a magic number where the blades are running faster than the shutter and it looks like the first one is on that line, where the second one has a slower shutter speed so the whole blade is blurred. Keep in mind that the RPM of the blade is greater the further you go from the center, so that first one, the center part is slower than the shutter but gets closer and passes that toward the edges.

  6. markc

    markc TPF Noob!

    Joined:
    Mar 8, 2004
    Messages:
    4,237
    Likes Received:
    6
    Location:
    Rochester, NY Velocity: Unknown
    Can others edit my Photos:
    Photos NOT OK to edit
    Oh duh. I forgot to mention swing-lens cameras like the Widelux. Using slow shutter speeds with those can get some weird effects if the subject is moving. I've wanted to own one for years.

  7. DocFrankenstein

    DocFrankenstein Clinically Insane?

    Joined:
    Apr 29, 2004
    Messages:
    1,646
    Likes Received:
    6
    It has nothing to do with slow shutter speed. In fact, the russian photo isn't slow shutter speed at all. It's 1/500 or 1/250


    The reason behind this is that it's probably shot with an old zenit. Curtain shutter with really slow curtains. 1/30 of a second to travel across the film plane.

  8. markc

    markc TPF Noob!

    Joined:
    Mar 8, 2004
    Messages:
    4,237
    Likes Received:
    6
    Location:
    Rochester, NY Velocity: Unknown
    Can others edit my Photos:
    Photos NOT OK to edit
    I didn't say that the original had anything to do with a slow shutter speed, but the Widelux images do. Find the book End Time City by Michael Ackerman and you will see lots of images taken with a slow shutter and a Widelux. The lens swings to cover a panorama. If the shutter is slow and the subject moves, they get either compressed or stretched. You can end up with a very similar effect. This happens with people just walking by, hence the slow, not fast, shutter.

  9. DocFrankenstein

    DocFrankenstein Clinically Insane?

    Joined:
    Apr 29, 2004
    Messages:
    1,646
    Likes Received:
    6
    My apologies.

  10. markc

    markc TPF Noob!

    Joined:
    Mar 8, 2004
    Messages:
    4,237
    Likes Received:
    6
    Location:
    Rochester, NY Velocity: Unknown
    Can others edit my Photos:
    Photos NOT OK to edit
    No problem. :D

  11. Torus34

    Torus34 No longer a newbie, moving up!

    Joined:
    Jan 26, 2006
    Messages:
    2,117
    Likes Received:
    37
    Location:
    Tottenville, Staten Island, NYC USA
    Can others edit my Photos:
    Photos OK to edit
    Effect due to focal plane shutter. Think of the shutter as a horizontal slit which moves from top to bottom. Also in the first shot remember that the blades on the helicopter are counter-rotating. When all blades are blurred, chances are shutter was a between-the-lens type which opens and closes radially.

  12. Unimaxium

    Unimaxium TPF Noob!

    Joined:
    Nov 13, 2004
    Messages:
    2,689
    Likes Received:
    22
    Location:
    Northeastern University, originally from Philly
    Can others edit my Photos:
    Photos OK to edit
    Small correction -- the RPM is the same at any point on the blade, but it is the speed (e.g. MPH) that is dependent on the radius. The outside of the blade turns just as many times a minute as the inside, but your point is still valid that the outside turns at a faster speed. Sorry, I'm just in a nit-picky mood today ;)

    My only guess as to why the second photo isn't curvy is the same as what the last poster suggested -- it was probably taken with a different camera that uses a different kind of shutter (one that works like an iris rather than a slit).
