Depth of Field (DOF) demo

Discussion in 'Photography Beginners' Forum' started by Ron Evers, Aug 28, 2010.

  1. Ron Evers

    Ron Evers Been spending a lot of time on here!

    Joined:
    Jun 28, 2008
    Messages:
    6,054
    Likes Received:
    1,893
    Location:
    In the country just north of Toronto, Canada
    Can others edit my Photos:
    Photos OK to edit
    I thought this might be helpful for the new-to-photography folks.

    I am presenting the same shot @ three different apertures to show how that relates to the DOF.


    1. f2.0

    [​IMG]


    2. f4.5

    [​IMG]


    3. f11

    [​IMG]


    You can see that as we use a higher f# we get less separation of the subject from the background. In this case @ f11 the dragonfly blends into the background but@ f2 it is separated from it.

    Taken with a Helios 58mm f2 manual lens on a Panasonic G1 mounted on a tripod. Pics are not cropped.

  2. crimbfighter

    crimbfighter No longer a newbie, moving up!

    Joined:
    Jun 4, 2010
    Messages:
    1,161
    Likes Received:
    433
    Location:
    Wisconsin, United States
    Can others edit my Photos:
    Photos OK to edit
    I noticed the color and sharpness in the third one are much better on the dragonfly. Is that mainly a function of the smaller aperture? Or were there any other factors that changed from picture to picture? I keep hearing the smaller apertures tend to be bet the sharpest on any lens.

  3. echoyjeff222

    echoyjeff222 No longer a newbie, moving up!

    Joined:
    Jun 27, 2010
    Messages:
    592
    Likes Received:
    100
    Location:
    WA
    Can others edit my Photos:
    Photos OK to edit
    great post for all the beginners learning aperture :)

  4. BuS_RiDeR

    BuS_RiDeR No longer a newbie, moving up!

    Joined:
    Oct 29, 2009
    Messages:
    2,356
    Likes Received:
    82
    Location:
    Riverview, New Brunswick, Canada.
    Can others edit my Photos:
    Photos OK to edit
    Good post...

    What lens did you use?

    My Canon 17-85 IS USM does not offer this DoF quality... Goes to show the importance of investing in good glass... Ah someday...

  5. Ron Evers

    Ron Evers Been spending a lot of time on here!

    Joined:
    Jun 28, 2008
    Messages:
    6,054
    Likes Received:
    1,893
    Location:
    In the country just north of Toronto, Canada
    Can others edit my Photos:
    Photos OK to edit
    The only thing I changed between shots was the aperture of the lens. However the camera automatically changed the shutter speed.

    Yes, in general the smaller the aperture (larger f#) the sharper the image.

  6. Negative ISO

    Negative ISO TPF Noob!

    Joined:
    Aug 25, 2010
    Messages:
    99
    Likes Received:
    0
    Location:
    Alaska
    Can others edit my Photos:
    Photos OK to edit
    Thanks for posting this, it is a nice example. The white balance appears to have changed between shots, and this confuses me. Is this a normal side effect of changing F-stop?

    Out of curiosity I dropped these JPGs into GIMP and tweaked the RED/GREEN levels of images 1 and 3 to match the white balance with the middle shot. In my results 1 & 2 look very similar, with subtle DOF changes. Image 3 still stands out with it's very different DOF.

    Thoughts?

  7. SageMark

    SageMark TPF Noob!

    Joined:
    Aug 16, 2010
    Messages:
    209
    Likes Received:
    0
    Location:
    Covington
    Can others edit my Photos:
    Photos OK to edit
    Great post.

  8. LuckySe7en

    LuckySe7en TPF Noob!

    Joined:
    Aug 18, 2010
    Messages:
    831
    Likes Received:
    47
    Location:
    Austin, TX
    Can others edit my Photos:
    Photos OK to edit
    thanks a lot for this. although my kit lense only drops to f4, I can still get a little blur.

  9. Ron Evers

    Ron Evers Been spending a lot of time on here!

    Joined:
    Jun 28, 2008
    Messages:
    6,054
    Likes Received:
    1,893
    Location:
    In the country just north of Toronto, Canada
    Can others edit my Photos:
    Photos OK to edit
    I noticed that too. The camera was on auto WB. I concluded, maybe wrongfully, that as the background had more influence it shifted the WB.

  10. kundalini

    kundalini Been spending a lot of time on here!

    Joined:
    Jul 18, 2007
    Messages:
    13,601
    Likes Received:
    1,929
    Location:
    State of Confusion
    Can others edit my Photos:
    Photos NOT OK to edit
    Nice examples Ron, but I would think that turning anything Auto to the OFF position would be the best for consistant and definitive results.

    Just my 2ยข.

  11. Ron Evers

    Ron Evers Been spending a lot of time on here!

    Joined:
    Jun 28, 2008
    Messages:
    6,054
    Likes Received:
    1,893
    Location:
    In the country just north of Toronto, Canada
    Can others edit my Photos:
    Photos OK to edit
    If you read the footnote in the original post you would know the answer Mark. ;)

    This Russian lens is very nice glass & I got it shipped all in for under $30. A lot of old 35mm film camera lenses are excellent & can be bought cheap on eBay particularly the ones made in the former Soviet Union. I have another 55mm 49mm Leica mount coming from Moscow that is highly prized & is reportedly sharper & more contrasty than the one used here. Supposed to be very sharp wide open @ f2.8, a little slower than the Helios 58/2.0. Should get it next week. :D

  12. eccs19

    eccs19 TPF Noob!

    Joined:
    Jun 30, 2008
    Messages:
    571
    Likes Received:
    6
    Location:
    Lisle Ontario Canada
    Can others edit my Photos:
    Photos OK to edit
    Shame I can't try it out on my camera when it shows up. I'd keep it for a few days before delivering it to you. :lol:
