Macro of Crystals

Discussion in 'Beyond the Basics' started by Mithlondor, May 10, 2007.

  1. Mithlondor

    Mithlondor TPF Noob!

    Joined:
    Jan 5, 2007
    Messages:
    34
    Likes Received:
    0
    Can others edit my Photos:
    Photos OK to edit
    [​IMG]

    This is a shot of 9-bromo-10-methylphenanthrene. The crystals were grown overnight (fast) so theyre a bit irregular. The shot itself was taken with a 50mm macro lense with the crystals mounted on a melting point apparatus, side lit with a magnifying glass locked in place over the crystals. The big problem im running into with this type of photography is one of sharpness/focus. Focusing through basically 2 lenses (the macro on the camera and the magnifying glass) from a distance of 2 inches (if that) is so incredibly touchy. Are there any tips on how to improve the setup or the focusing technique? I would really like to take more pictures like this and I dont necessarily want to get into buying a microscope setup with a camera mount (especially since theres no way I could write a microscope into my research grants).

  2. LaFoto

    LaFoto Just Corinna in real life Staff Member Supporting Member

    Joined:
    Feb 1, 2004
    Messages:
    34,814
    Likes Received:
    814
    Location:
    Lower Saxony, Germany
    Can others edit my Photos:
    Photos NOT OK to edit
    I think this question is better put in "Beyond the Basics", because that is where you want to step with your kind of macro photography (which I find fascinating, by the way).
    Sorry, I cannot give you an answer to your question, though.

  3. Mithlondor

    Mithlondor TPF Noob!

    Joined:
    Jan 5, 2007
    Messages:
    34
    Likes Received:
    0
    Can others edit my Photos:
    Photos OK to edit
    Well, I appreciate the pointer :) Sorry for posting it in the wrong place!

  4. Garbz

    Garbz No longer a newbie, moving up!

    Joined:
    Oct 26, 2003
    Messages:
    9,713
    Likes Received:
    203
    Location:
    Brisbane, Australia
    Can others edit my Photos:
    Photos NOT OK to edit
    As you mentioned it's touchy and from the looks of things a touch out of focus. I'd be inclined to attempt to mount both camera and magnifying glass on some kind of support to allow very fine adjustments to focusing.

    It wouldn't have to be too robust. Just enough to support it's own weight, so a structure of cardboard or wood work work.

  5. Alex_B

    Alex_B No longer a newbie, moving up!

    Joined:
    Aug 30, 2006
    Messages:
    14,491
    Likes Received:
    206
    Location:
    Europe 67.51°N
    Can others edit my Photos:
    Photos NOT OK to edit
    I agree with what Garbz said, it would be best if all (camera nad magnifying glass) where mounted onto something solid.. best something which allows easy and fine-tunable shifting.

  6. Mike_E

    Mike_E No longer a newbie, moving up!

    Joined:
    Jan 26, 2007
    Messages:
    5,327
    Likes Received:
    264
    Location:
    The Upper West Side of Mississippi (you have no i
    Can others edit my Photos:
    Photos OK to edit
    Mythlondor, I don't know if this will work as I only have one set of extension tubes, but here is something you might persue. First how about 2 sets of extension tubes? One works pretty well maybe 2 is better?

    Also, there are rings to screw one lens backwards onto front of another for macro shots as well, how about a set of extension tubes and the backwards lens too? Or all three?

    Anyway, 2 sets of extension tubes and the ring- for Nikon at least- is around $40 shipped for all of it, which is a lot less than a good microscope setup.

    Just a thought

    mike

  7. Mithlondor

    Mithlondor TPF Noob!

    Joined:
    Jan 5, 2007
    Messages:
    34
    Likes Received:
    0
    Can others edit my Photos:
    Photos OK to edit
    Yeah extension tubes might help. The problem is that the camera has to be directly above the subject, and with a 50 mm macro lense, you have to get REALLY REALLY close for 1:1. That makes tripod use very difficult.

  8. smyth

    smyth TPF Noob!

    Joined:
    Jan 19, 2007
    Messages:
    372
    Likes Received:
    0
    Location:
    Ottawa, Ontario
    Can others edit my Photos:
    Photos OK to edit
    close up filters maybe?

  9. Mike_E

    Mike_E No longer a newbie, moving up!

    Joined:
    Jan 26, 2007
    Messages:
    5,327
    Likes Received:
    264
    Location:
    The Upper West Side of Mississippi (you have no i
    Can others edit my Photos:
    Photos OK to edit
    I've got a 70-210 push-pull zoom that I use the tubes with and just zoom for focus. I do have to be close but the zoom gives some lea-way.

    Besides, you'd have pretty close with a microscope too. ;)

    mike

  10. (Ghastly) Krueger

    (Ghastly) Krueger TPF Noob!

    Joined:
    Feb 20, 2006
    Messages:
    1,393
    Likes Received:
    0
    Location:
    Lost between tomorrow and yesterday
    Can others edit my Photos:
    Photos OK to edit
    Depending on the size and bulk of the melting point apparatus, it might be easier to move it instead of the camera + lens + mag glass. Just a point to consider. Also, the same precaution as working with a microscope: don't run the lens into the objective! ;)
