Macro question

Discussion in 'Photography Beginners' Forum' started by Brutus, Aug 26, 2008.

  1. Brutus

    Brutus TPF Noob!

    Joined:
    Aug 24, 2008
    Messages:
    216
    Likes Received:
    0
    I'm wondering how people take certain macros. Some you can take freehand, but the super close ones, and I'm sure most of the really good ones, seem to have to be taken with a tripod. How do you get so close to the subject with a tripod, though? The legs distance the camera from whatever object you're trying to photograph, are there certain tripod that eliminate this?

  2. icassell

    icassell TPF Noob!

    Joined:
    Jun 7, 2008
    Messages:
    9,893
    Likes Received:
    10
    Location:
    Arizona
    Can others edit my Photos:
    Photos NOT OK to edit
    Some tripods (not mine) have a horizontal arm to put the camera out away from the pod.

  3. tirediron

    tirediron Watch the Birdy! Staff Member Supporting Member

    Joined:
    Jul 8, 2005
    Messages:
    37,316
    Likes Received:
    10,635
    Location:
    Victoria, BC
    Can others edit my Photos:
    Photos OK to edit
    I use a Manfrotto 190Pro with a centre column that can be set horizontally along with a macro focusing rail. For stuff that doesn't have to be shot in situ, I have a macro stand made out of an old enlarge chassis that allows for extremely precise movement of the camera.

  4. epp_b

    epp_b No longer a newbie, moving up!

    Joined:
    Aug 22, 2008
    Messages:
    2,135
    Likes Received:
    12
    Location:
    True North Cold and Freezing
    Can others edit my Photos:
    Photos OK to edit
    With a longer macro lens ;)

  5. Battou

    Battou No longer a newbie, moving up!

    Joined:
    May 10, 2007
    Messages:
    7,997
    Likes Received:
    26
    Location:
    Slapamonkey, New York
    Can others edit my Photos:
    Photos NOT OK to edit
    There are a handful of different ways. Yes a tripod is a must, along with mirror lock, and Delayed shutter release.

    I use a cheap wall mart tripod and bellows and it works well enough for me. As far as lenses go I have macro shot super close with all sorts of lenses including a 50mm 1.4 standard prime (used here). Although one of my favorites is prolly a 135mm (Setup seen Here)

    When shooting macro like this, stationary objects is your best friend. When using mirror lock, delayed release, long exposures, and small apertures some really neat things can be done with Macro.


    Additionally, I like to keep several flashlights handy, they are far more reliable than a flash for those tricky lighting situations. In fact I won't use a flash for macro work my self, but there are others here that swear by them.



    *EDIT*

    WOW, I misread the OP, I second what epp_b sais, use a longer lens.

  6. Caleb W.

    Caleb W. TPF Noob!

    Joined:
    Aug 21, 2008
    Messages:
    43
    Likes Received:
    0
    Location:
    Capron, Illinois
    Can others edit my Photos:
    Photos OK to edit
    For all my macro work I use a Manfrotto 055XPROB with a pistol grip head.

  7. Overread

    Overread has a hat around here somewhere Staff Member Supporting Member

    Joined:
    May 1, 2008
    Messages:
    23,083
    Likes Received:
    3,752
    Location:
    UK - England
    Can others edit my Photos:
    Photos OK to edit
    I think also most of the super close shots are taken at greater than 1:1 macro - 1:1 and 2:1 macro (that is a normal macro lens with 2*teleconverter) are handholdable - though definatly not simple (especially with 2:1).
    Past that you really do need to have a tripod as the plane of focus is so small. Further you are then into the realms of adding lots of additional bits to your lens or (better) using a canon MPE 65 macro - which can get to 5:1 macro (and is infact the only lens to do so - yep nikon don't make one!)

  8. Battou

    Battou No longer a newbie, moving up!

    Joined:
    May 10, 2007
    Messages:
    7,997
    Likes Received:
    26
    Location:
    Slapamonkey, New York
    Can others edit my Photos:
    Photos NOT OK to edit
    No, A TC effects a Macro lens the same way it effects a normal lens. Atrificially inflating focal length, not macro scale. If you want to push the Macro ratio you need extention tubes. Extention tubes are different in thay do not have glass in them.

    The Glass in a TC magnyfies an image a little yes, but it's within Xx# bounds of the lenses focusing range as it applies to the film plane, you and your camera body can be further away to focus on the subject at hand. An extention tube however move the lens away form the sensor/film plain. This changes the point in wich the light bends before reaching the sensor. ET allow you to get closer with the lens, but the film plane must stay with in the focusing range of the lens at hand as if the lens where on the body. The farther you get the lens from the camera body the bigger the macro ratio.....I think.


    I could be wrong on the technical stuffs, I don't play with tech books and numbers, I just tinker with equipment till it looks cool, but one thing I know is right is that a TC is not a macro enabling device, the extention tube is.

  9. Overread

    Overread has a hat around here somewhere Staff Member Supporting Member

    Joined:
    May 1, 2008
    Messages:
    23,083
    Likes Received:
    3,752
    Location:
    UK - England
    Can others edit my Photos:
    Photos OK to edit
    hmm I agree on a non macro lens that a TC is not macro enablaing whilst an extension tube is, but I am sure I have read (by another hand) that a teleconverter on a macro lens increases magnification.

  10. Battou

    Battou No longer a newbie, moving up!

    Joined:
    May 10, 2007
    Messages:
    7,997
    Likes Received:
    26
    Location:
    Slapamonkey, New York
    Can others edit my Photos:
    Photos NOT OK to edit

    Well give me a week and I'll find out one way or another, I have a 2X TC and a Macro prime and a bellows. I just have to take the shots.

    I did expariment with a TC'd 50mm 1.4 with macro filters, the results where that of a 100mm with macro filters, it was the results I was was expecting but the photos where pretty much crap. I'll have to process those in a little wile just because.

  11. Overread

    Overread has a hat around here somewhere Staff Member Supporting Member

    Joined:
    May 1, 2008
    Messages:
    23,083
    Likes Received:
    3,752
    Location:
    UK - England
    Can others edit my Photos:
    Photos OK to edit
    did some reading - Closeup and Macro A Photographers Guide by Robert Thompson - he writes that teleconverters do extend the focal length - meaning a greater working distance and that they also increase the level of magnification.
    also from my own works - this shot was taken with the 150mm macro and a 2*teleconverter:
    [​IMG]

    whilst this is as close (and as big) as I can get with only the 1.4 TC
    [​IMG]

    of course one has to be focused at the maximum point to get this effect - and 2* is hard to focus and compose with - really its a tripod combo for resting insects and stacked shots

  12. icassell

    icassell TPF Noob!

    Joined:
    Jun 7, 2008
    Messages:
    9,893
    Likes Received:
    10
    Location:
    Arizona
    Can others edit my Photos:
    Photos NOT OK to edit
    Wow, that first fly needs a shave!

    I never thought to try my TC's with my macro lens -- gonna have to try it!
