Newton's Rings on my DSLR?

Discussion in 'General Gallery' started by jspitfire, Mar 11, 2008.

  1. jspitfire
    Offline

    jspitfire New Member

    Joined:
    Mar 11, 2008
    Messages:
    8
    Likes Received:
    0
    Trophy Points:
    0
    Gallery:
    Ratings:
    +0 / 0
    Hello all, new to the forums here, hopefully someone knows how to fix my problem. I've been out a couple times to take pictures of the Aurora Borealis, and on both occasions have had what appears to be newton's rings in the centre of almost all my pictures.

    It was somewhat cold out (-25 Celcius the first time, -5 the second), but I've been out many times taking other night shots (in temps as low as -40) and have never seen this problem. Granted for the Aurora I was out for at least 45 minutes though, which is much longer than I usually stay out when its that cold! Here is an example:

    [​IMG]

    I am using a Canon Rebel XTi. If anyone knows where in the camera this is happening and how to fix it, I would certainly love to know!

    Thanks

    Jason
  2. BYoung
    Offline

    BYoung New Member

    Joined:
    Jan 4, 2008
    Messages:
    163
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Northwest Territories, Canada
    Gallery:
    Ratings:
    +0 / 0
    This is odd. I also have a XTi and have taken pictures in the middle of winter but I have not had this issue. I've been outside in -40 C with my camera for well over an hour a few times.

    Did you inspect both ends of the lens and make sure its not that or a filter you have?

    Also what lens were you using?
  3. jspitfire
    Offline

    jspitfire New Member

    Joined:
    Mar 11, 2008
    Messages:
    8
    Likes Received:
    0
    Trophy Points:
    0
    Gallery:
    Ratings:
    +0 / 0
    Thanks for the quick reply.
    I will try taking the filter off next time I go out. I have a Canon 24-85mm f3.5-4.5
  4. BYoung
    Offline

    BYoung New Member

    Joined:
    Jan 4, 2008
    Messages:
    163
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Northwest Territories, Canada
    Gallery:
    Ratings:
    +0 / 0
    I'm new to photography, well around 5 months now, so I have never seen these rings before. but inspecting the lens & filter seemed like a great place to start.

    Where you from to see awesome lights like this? My avatar says where I am.

    Here is a pic I took the other night you might enjoy along with yours.
    [​IMG]
  5. jspitfire
    Offline

    jspitfire New Member

    Joined:
    Mar 11, 2008
    Messages:
    8
    Likes Received:
    0
    Trophy Points:
    0
    Gallery:
    Ratings:
    +0 / 0
    Cool shot there! I just moved up to Yellowknife a couple months ago.

    My pic was from this past Saturday night, the aurora was pretty intense!
  6. BYoung
    Offline

    BYoung New Member

    Joined:
    Jan 4, 2008
    Messages:
    163
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Northwest Territories, Canada
    Gallery:
    Ratings:
    +0 / 0
    Ah crazy crazy man, I'm from Hay River. We are a massive lake apart.

    I took this pic 2 nights ago.
  7. CanAm
    Offline

    CanAm New Member

    Joined:
    Mar 4, 2008
    Messages:
    113
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    San Jose, CA
    Gallery:
    Ratings:
    +0 / 0
    It is my resolve to see one of the Auroras before I die.

    And hopefully photograph it.
  8. fokker
    Offline

    fokker Well-Known Member

    Joined:
    Jun 23, 2009
    Messages:
    2,832
    Likes Received:
    293
    Trophy Points:
    83
    Location:
    New Zealand
    Gallery:
    Ratings:
    +293 / 0
    Bumping an old thread here to see if anybody has a good explanation for these Newton's Rings. I have a similar photo with the exact same phenomenon:


    The two things I keep seeing in common with other people experiencing these Newton's Rings are Auroral activity and UV filters. I believe there is some Aurora activity in this photo, though only faint. I never noticed it with my naked eye. This photo is from a couple of years ago and I can't remember if I was using a UV filter - it's possible but unlikely.
  9. paigew
    Offline

    paigew Well-Known Member

    Joined:
    Nov 15, 2011
    Messages:
    2,740
    Likes Received:
    900
    Trophy Points:
    113
    Location:
    Austin
    Gallery:
    Ratings:
    +904 / 1
    Interesting! I have never heard of this before. Great photos.


    Sent from my iPhone using Tapatalk
  10. pgriz
    Offline

    pgriz Well-Known Member

    Joined:
    Jul 30, 2010
    Messages:
    4,867
    Likes Received:
    2,230
    Trophy Points:
    113
    Location:
    Canada
    Gallery:
    Ratings:
    +2,253 / 1
    Newton's rings are an interference pattern set up between a curved surface and a flat surface (so lens + filter combination seems to be part of this), with a monochromatic lights (light from the aurora tends to be of several well-defined wavelengths (see: Auroral Colors and Spectra - Windows to the Universe) with the green line at 558 nm being quite prominent.
  11. Theo2
    Offline

    Theo2 New Member

    Joined:
    Jul 3, 2014
    Messages:
    85
    Likes Received:
    24
    Trophy Points:
    0
    Location:
    United States
    Gallery:
    Ratings:
    +24 / 0
    I demonstrated this last semester on a lens to a bunch of freshman physics majors! (Almost) Definitely the flat glass (filter) and convex glass (lens).
  12. KmH
    Offline

    KmH Helping photographers learn to fish

    Joined:
    Apr 9, 2009
    Messages:
    34,037
    Likes Received:
    4,058
    Trophy Points:
    113
    Location:
    Iowa
    Gallery:
    Ratings:
    +4,063 / 0
    Lose the mostly useless for protection, but otherwise problem causing UV filter.
