Reverse prime macro lens

Discussion in 'Beyond the Basics' started by Dmitri, Apr 16, 2010.

  1. Dmitri

    Dmitri No longer a newbie, moving up!

    Joined:
    Jun 20, 2008
    Messages:
    5,872
    Likes Received:
    38
    Location:
    End of the line
    Can others edit my Photos:
    Photos NOT OK to edit
    I've been having some fun with this, but the DOF is crazy small... is this normal for macro photography or is it just because I'm cheesing it?

  2. Derrel

    Derrel Mr. Rain Cloud

    Joined:
    Jul 23, 2009
    Messages:
    35,456
    Likes Received:
    12,794
    Location:
    USA
    Can others edit my Photos:
    Photos OK to edit
    Shallow DOF is pretty normal when doing ultra-close or high-magnification photography. it doesn't matter if you have high-quality reversing rings, or are just holding a lens in reverse over the lens mount by hand---the resulting DOF is going to be small.

  3. Dmitri

    Dmitri No longer a newbie, moving up!

    Joined:
    Jun 20, 2008
    Messages:
    5,872
    Likes Received:
    38
    Location:
    End of the line
    Can others edit my Photos:
    Photos NOT OK to edit
    ok, just making sure. Thanks Derrel :)

  4. Dmitri

    Dmitri No longer a newbie, moving up!

    Joined:
    Jun 20, 2008
    Messages:
    5,872
    Likes Received:
    38
    Location:
    End of the line
    Can others edit my Photos:
    Photos NOT OK to edit
    Thats some DOF lol

    [​IMG]

  5. Overread

    Overread has a hat around here somewhere Staff Member Supporting Member

    Joined:
    May 1, 2008
    Messages:
    23,084
    Likes Received:
    3,753
    Location:
    UK - England
    Can others edit my Photos:
    Photos OK to edit
    Neat money shot ;)!

    But yes as Derral said no matter the method you use as magnification goes up the depth of field starts to drop off. You can lower your aperture to counter this, but also note that in most setups as you increase magnification your diffraction limit will also change accordingly.
    Have a look at this set here: MPE 65mm test shot series - a set on Flickr

    You can view the fullsized images there and see for yourself how diffraction starts to become more and more of a problem as the magnification goes up. I'd honestly spend an hour or two testing this with your setup(s) just to get an idea of where the new sweetspots for sharpness are

  6. Dmitri

    Dmitri No longer a newbie, moving up!

    Joined:
    Jun 20, 2008
    Messages:
    5,872
    Likes Received:
    38
    Location:
    End of the line
    Can others edit my Photos:
    Photos NOT OK to edit
    :lol::lol::lol::lol::lol:

    Well I'm just hand-holding my 50mm backwards, so it's not exactly a "setup" :) Just having some fun and wanted to know if the DOF was all macro shots or the fact that I have 0 aperature lol

  7. Derrel

    Derrel Mr. Rain Cloud

    Joined:
    Jul 23, 2009
    Messages:
    35,456
    Likes Received:
    12,794
    Location:
    USA
    Can others edit my Photos:
    Photos OK to edit
    Dmitri--A neat "trick" or workaround with a Canon EOS mount lens used in reverse is to mount the lens on the body normally, and press the camera's depth of field preview button and then remove the lens from the body while continuing to hold the DOF preview button in and the camera still switched to ON. That will keep the lens stopped down! This is the only way for the user to control the aperture of a reverse-mounted Canon EOS lens, or when using those ultra cheap-o aftermarket extension tubes that have no electrical contacts.

    Reverse-mounting a lens that has a diaphragm control ring on it, like an older Pentax M42 or K-mount, Nikon F, Minolta MD, Olympus OM, or Canon FD-mount lens (plus others) is pretty straightforward, since all those lens mounts use a mechanical aperture control ring on each and every lens.

  8. Overread

    Overread has a hat around here somewhere Staff Member Supporting Member

    Joined:
    May 1, 2008
    Messages:
    23,084
    Likes Received:
    3,753
    Location:
    UK - England
    Can others edit my Photos:
    Photos OK to edit
    Of course the downside to the stopping down trick is that it makes your viewfinder image much darker since the aperture blades are blocking the light. I tend to use a little single bulb LED torch on a flexi arm to help give a little pinpoint of light to help focus. Indoors (where things are really quite dark) I find it very essential.

    The only other way is to use a Novoflex reverse mount adaptor controler thingy, but unless you find one second hand its price new is very prohibative unless you intend to do a lot of reverse mounted work.

  9. Derrel

    Derrel Mr. Rain Cloud

    Joined:
    Jul 23, 2009
    Messages:
    35,456
    Likes Received:
    12,794
    Location:
    USA
    Can others edit my Photos:
    Photos OK to edit
    [​IMG]

    If you keep the subject matter perfectly parallel with the back of the camera, you have something like one millimeter's worth of depth of field to play around with. As overread points out, it can be very difficult to see through the camera with the lens stopped down to working aperture, so the small LED flashlight as a focus-assist light makes a huge amount of sense. In the above photo, I could barely see through the stopped-down lens, and ended up shooting ten frames just to get a couple good, sharp shots where the depth of field band was precisely aligned with the penny's surface and the currency's surface, which was about .9mm behind the coin's main surface, give or take.

  10. Dmitri

    Dmitri No longer a newbie, moving up!

    Joined:
    Jun 20, 2008
    Messages:
    5,872
    Likes Received:
    38
    Location:
    End of the line
    Can others edit my Photos:
    Photos NOT OK to edit
    Holy crap that DOF trick is awesome!!!!

    From
    [​IMG]
    To
    [​IMG]

    Overread: Yeah I noticed! lol Between holding the lens up, needing a flash and a light to see f/22 spur of the moment photos may be tough ;)

    Derrel: Great shot of Lincoln-moneys! Thanks for the info and the DOF tip!

  11. Overread

    Overread has a hat around here somewhere Staff Member Supporting Member

    Joined:
    May 1, 2008
    Messages:
    23,084
    Likes Received:
    3,753
    Location:
    UK - England
    Can others edit my Photos:
    Photos OK to edit
    Yep! Though personaly I would try to stick to aperture values wider than f16 - Infact I tend to keep f13 as my main limit because of diffraction. If you start getting much smaller no matter how well you take the shot the overall end result will be noticably softer. I've no idea quite how this changes when you reverse the lens, but it would be interesting to see where the diffration limit is sitting.

  12. Dmitri

    Dmitri No longer a newbie, moving up!

    Joined:
    Jun 20, 2008
    Messages:
    5,872
    Likes Received:
    38
    Location:
    End of the line
    Can others edit my Photos:
    Photos NOT OK to edit
    Thanks, and I think you're right. I remember reading somewhere that most lenses have f/8 and f/16 as the "sweet spots".
