Viewfinder VS captured image. Help please

Discussion in 'Photography Beginners' Forum' started by I X L R 8, Aug 18, 2010.

  1. I X L R 8

    I X L R 8 TPF Noob!

    Joined:
    Jul 28, 2010
    Messages:
    141
    Likes Received:
    0
    Location:
    texas
    I have , for a long time , been under the impression that SLR cameras capture the exact image seen in the viewfinder.

    I'm finding for some reason that this is not the case with digital.

    Also, I'm not so sure it was the case with my Minolta 700si 35mm film camera.

    On the Sony A550, the processed image, is larger than the image seen in the viewfinder before the shot.

    In other words, if I put the edge of the frame in the viewfinder, on a lateral line and then snap the shot, the processed image overlaps the line.

    This is hard to explain.

    I'm wondering if there is a setting that allows to capture the exact image seen in the viewfinder?????

    I've noted that when I change aspect ratios and megapixels, this does change some but it is still not the exact image seen in the viewfinder.

    Anyone?

  2. I X L R 8

    I X L R 8 TPF Noob!

    Joined:
    Jul 28, 2010
    Messages:
    141
    Likes Received:
    0
    Location:
    texas
    bump

  3. Brutus

    Brutus TPF Noob!

    Joined:
    Aug 24, 2008
    Messages:
    216
    Likes Received:
    0
    I believe there is normally a magnification factor in most viewfinders.

  4. AdrianC

    AdrianC TPF Noob!

    Joined:
    Aug 1, 2010
    Messages:
    155
    Likes Received:
    0
    Location:
    Edmonton
    Can others edit my Photos:
    Photos OK to edit
    That's just how the camera was designed. I remember reading about it in my user manual a couple of yrs ago.

    You could just crop it during post processing.

  5. Bitter Jeweler

    Bitter Jeweler Been spending a lot of time on here!

    Joined:
    Apr 27, 2009
    Messages:
    12,984
    Likes Received:
    4,971
    Location:
    Cleveland, Ohio
    Can others edit my Photos:
    Photos OK to edit
    You really want to over shoot anyways. This gives you room to refine the crop later. So, look at it as a positive.

  6. I X L R 8

    I X L R 8 TPF Noob!

    Joined:
    Jul 28, 2010
    Messages:
    141
    Likes Received:
    0
    Location:
    texas
    Thank you.
    I found the problem.

    16:9 aspect ratio changes the image capture seen in the viewfinder.

    I changed that back to 3:2 aspect ratio which is the equivalent of a 35mm.
    The camera became MUCH MORE viewfinder to processed image friendly.

    Obviously I don't know what I'm doing.
    But alas , all is not lost.
    I'm trying to figure it all out.

  7. Dwig

    Dwig TPF Noob!

    Joined:
    Mar 11, 2009
    Messages:
    1,261
    Likes Received:
    0
    Location:
    Key West FL
    Can others edit my Photos:
    Photos NOT OK to edit
    You have been living with a false impression. Almost none ever have.

    With a few exceptions, neither film nor digital SLRs have extremely accurate VFs. In almost all cases the VF image is 5-10% smaller area than the actual film or sensor. Making an SLR VF perfectly accurate is extremely difficult (read: expensive).

  8. Scatterbrained

    Scatterbrained Been spending a lot of time on here!

    Joined:
    Apr 19, 2010
    Messages:
    2,181
    Likes Received:
    1,081
    Location:
    Yucca Valley, Ca
    Can others edit my Photos:
    Photos NOT OK to edit
    +1. If you look most cameras will have a specification for viewfinder coverage area. I think mine is about 95%, which means that 5% of what will be captured by my camera cannot be seen through the viewfinder. I've just adjusted to cropping that extra out of my images.

  9. Dao

    Dao No longer a newbie, moving up!

    Joined:
    Mar 24, 2008
    Messages:
    6,252
    Likes Received:
    418
    Location:
    St. Louis
    I do not think it is going to be exactly the same, but in general, those camera bodies that cost more have more coverage.

    My Canon 40D claims to be 95% frame coverage while 1Ds MKIII is 100%.

    And your A550 also claims to be 95% frame coverage.

  10. KmH

    KmH Helping photographers learn to fish Supporting Member

    Joined:
    Apr 9, 2009
    Messages:
    38,240
    Likes Received:
    5,009
    Location:
    Iowa
    Can others edit my Photos:
    Photos OK to edit
    When you look in the viewfinder the lens is kept wide open so the viewfinder is a bright as possible.

    When the shutter is released, or a DOF preview button is pressed, THEN the lens aperture is physically set by the camera.

    At any rate the light path to get the scene up to the eye is different than the light path to the image sensor.
    Additionally, the image sensor doesn't work like your eye does.


    [​IMG]




    Cross-section view of DSLR system:
    1. 4-element lens
    2. Reflex mirror
    3. Focal-plane shutter
    4. Image sensor
    5. Matte focusing screen
    6. Condenser lens
    7. Pentaprism or Pentamirror
    8. Eyepiece
    I, Cburnett, the copyright holder of this work, hereby publish it under the following licenses:
    Permission is granted to copy, distribute and/or modify this document under the terms of the GNU Free Documentation License, Version 1.2 or any later version published by the Free Software Foundation; with no Invariant Sections, no Front-Cover Texts, and no Back-Cover Texts. A copy of the license is included in the section entitled "GNU Free Documentation License".

  11. Taylor510ce

    Taylor510ce TPF Noob!

    Joined:
    Jul 20, 2010
    Messages:
    702
    Likes Received:
    1
    Location:
    United States
    Can others edit my Photos:
    Photos NOT OK to edit
    Canon 7D has 100%

  12. I X L R 8

    I X L R 8 TPF Noob!

    Joined:
    Jul 28, 2010
    Messages:
    141
    Likes Received:
    0
    Location:
    texas
    thank you all for being so helpful.

    The 3.2 aspect ratio cured the problem I was having.
    With this ratio, a bit more is captured " evenly on all sides" than what I see in the viewfinder.

    The 16:9 ratio distorts the processed image. Dont ask me why.
    I'M QUITE OBVIOUSLY A ROOKIE.
