    Yi-M1 "HDR"
    - 42.5mm F1.8 Macro/Portrait lens

    This project started when I decided to post some pictures of my Sony a5000 using my Minolta 28-100 zoom. I expected to take a couple of quick "snap-shots" and post them. But when I saw the results I was disappointed and ended up working on the DNG files until I got fairly acceptable results.
    [see: ""Konica Minolta 28-100mm f/3.5-5.6 D AF Zoom" #9" Konica Minolta 28-100mm f/3.5-5.6 D AF Zoom]

    After I was done, it remained on my mind and I had a couple of approaches for improvement. The first was a simple change in the exposure to EV = +1.0. The second was to finally try out the HDR capability of the Yi-M1. Later in the evening I decided that it was a good idea for me to take the extra time and try out the HDR capability of the camera, so the decision was made to continue this as a new project.

    One reason I have not gotten around to trying the HDR mode on the Yi-M1 was because the camera does not save a RAW (DNG) file when it is used this way. I guess that this is probably because it is doing so much and taking its time just making the HDR. If there were an option to save a RAW, what kind of file would it be? I would be happy it the camera saved the RAW image indicated by the EXIF data.


    About HDR:
    NOTE: This forum has a specific area to discuss HDR which I have not had time to look into yet.

    As far as I know, "HDR" and "WDR" mean the same thing. Both terms were coined by people trying to cope with the problem of making pictures where the dynamic range of the subject matter exceeded the inherent reciprocity of the hardware. The techniques go back to the concepts like "dodging and burning" and other techniques developed in film photography to cope with the same problem. Some companies might be trying to define certain techniques as one or the other, but I have seen the terms used interchangeably, and I have not seen anyone state a specific difference. If anyone knows, or even "thinks" otherwise, let me know.


    This Image Set:

    I used a slightly different but similar setup as yesterday, but the lighting is a bit less diffused this time. For this set of images I also decided to control the depth of field by using "Aperture Priority" and working with F8 and F11, and in the latter pictures selecting the point of focus with the touch screen.

    I am not planning on posting "detail" crops for this set.


    "PC210003a-rsz1640-C1.JPG"

    I started this project with three images taken "regularly" with EV = +1.0 and DNG files. This is the last image with DNG. All the rest are HDRs. This is my "control" image. If I had taken yesterday's pictures with EV = +1.0 then I would have probably still worked with some of the DNG files, but I would have had an easier time, and probably better results. I probably would have posted this picture as-is. There is sufficient shadow detail to show the equipment using the adapter's tripod mount and how high it raises the camera. I was not trying to make it look "pretty", I was only trying to show the equipment I had been using lately.

    Partial EXIF
    Dimensions 5184 x 3888
    Color representation Uncalibrated (AdobeRGB)
    F-stop f/8
    Exposure time 1/100 sec.
    ISO speed ISO-3200
    Exposure bias +1 step
    Focal length 43 mm
    Max aperture 3.65
    Metering mode Center Weighted Average
    35mm focal length 86
    Exposure program Aperture Priority (forced F8)


    "PC210005a-rsz1640-C1.JPG"

    This file replicated most of the settings of "03" except that it is set for HDR and no RAW. Notice how that exposure time jumps from 1/100 sec. to 1/5 sec. and the ISO drops from ISO-3200 down to ISO-200. I did not do that, the HDR setting did that. Also, the picture is slightly zoomed/cropped compared to the control picture. If size is critical, one might have to anticipate, and maybe even calculate this difference. Also, the exposure is still EV = +1.0. In picture "11" below, using EV = +0, shadow detail starts to go away. So correct exposure is still a "judgement call" and bracketing is a good idea. I consider this image to be "almost perfect". The highlights have been muted bringing out the "AF 28-100" label and the exposure of the bright area on the lens mount is also reduced. Part of the camera body and parts of the tripod mount are sitting a bit too close to the "floor black" than I would like, but there is no detail of interest in those areas anyway. Likewise, at the front of the lens there is some silver area which is just inside the "white" value.

    Partial EXIF
    Dimensions 5184 x 3888
    Color representation Uncalibrated (AdobeRGB)
    F-stop f/8
    Exposure time 1/5 sec.
    ISO speed ISO-200
    Exposure bias +1 step
    Focal length 43 mm
    Max aperture 3.65
    Metering mode Center Weighted Average
    35mm focal length 86
    Exposure program Aperture Priority (forced F8)


    "PC210007a-rsz1640-C1.JPG"

    This file has slight composition changes (the angle of view) and F11 is used to increase the depth of field. The focus distance has been adjusted by using the touch screen focus in order to best use the depth of field. I tried a few focus points and this one turned out the best. I do not think there is a good way to check depth of field on this camera.

    Partial EXIF
    Dimensions 5184 x 3888
    Color representation Uncalibrated (AdobeRGB)
    F-stop f/11
    Exposure time 1/2 sec.
    ISO speed ISO-200
    Exposure bias +1 step
    Focal length 43 mm
    Max aperture 3.65
    Metering mode Center Weighted Average
    35mm focal length 86
    Exposure program Aperture Priority (forced F11)


    "PC210011a-rsz1640-C1.JPG"

    This file has another composition changes (angle of view) and it tests setting the Exposure Bias = +0.0. The average brightness of the image is darker, but the highlights and "floor black" still seem to be "contained." Comparing the two, I think it is best to adjust the exposure compensation as if it was a normally exposured picture. The lettering at the front of the lens is falling out of the depth of field, but I think if I had focussed a bit more towards the front of the camera I could have covered it without the "Sony" label losing sharpness.

    Partial EXIF
    Dimensions 5184 x 3888
    Color representation Uncalibrated (AdobeRGB)
    F-stop f/11
    Exposure time 1/5 sec.
    ISO speed ISO-200
    Exposure bias +0 step
    Focal length 43 mm
    Max aperture 3.65
    Metering mode Center Weighted Average
    35mm focal length 86
    Exposure program Aperture Priority (forced F11)


    Conclusion:

    The HDR setting can be useful, but yes, it takes a bit of practice to get the most out of it. It still helps to set the exposure compensation appropriately.

    NOTE: Due to upload problems the rest of the files were uploaded 2017-12-22 09:31.




    Attached Files:

    Last edited: Jan 11, 2018 at 8:35 PM
  2. jcdeboever

    jcdeboever TPF Supporters Supporting Member

    Joined:
    Sep 5, 2015
    Messages:
    14,047
    Likes Received:
    7,468
    Location:
    Michigan
    Can others edit my Photos:
    Photos OK to edit
    micro contrast is lacking.

  3. VidThreeNorth

    VidThreeNorth TPF Noob!

    Joined:
    Oct 21, 2016
    Messages:
    107
    Likes Received:
    6
    Can others edit my Photos:
    Photos NOT OK to edit
    What are you referring to?

  4. jcdeboever

    jcdeboever TPF Supporters Supporting Member

    Joined:
    Sep 5, 2015
    Messages:
    14,047
    Likes Received:
    7,468
    Location:
    Michigan
    Can others edit my Photos:
    Photos OK to edit
    The look of the images. Not impressed at all.

    • Agree Agree x 1
  5. VidThreeNorth

    VidThreeNorth TPF Noob!

    Joined:
    Oct 21, 2016
    Messages:
    107
    Likes Received:
    6
    Can others edit my Photos:
    Photos NOT OK to edit


    Yi-M1 Touch-Screen Focus Test
    (Partial report -- for now, consider this a partially uncompleted test. I considered abandoning this test and re-starting it with the "3.0 Int" firmware. Shortly after I upgraded the firmware, the flowers were gone, so now I would have to pick a completely new subject, or wait till next year.)

    Firmware version "2.0 Int"
    Lens: Yi 42.5mm Portrait/Macro


    In late August I decided that I wanted to test the accuracy and speed of the screen touch focus (and shoot) functions on the Yi-M1. I thought it should be easy. I just had to set up the camera on a tripod and use the screen touch to alternate between a "far" focus point and a "near" focus point. I thought that about 20 pictures of each to get the speed of the focus. I ran the test twice for about 80 total files.

    When I looked at the files on the computer I found out that the "time" on the files were reported down to the minute rather than down to the second. When I checked the EXIF internal information I found the same thing. The problem is that I would need many pictures to get a good calculation of the speed. Or I needed a better method of testing. I could use a stop-watch (which I have), or perhaps I could set up a camcorder on another tripod behind the test unit and take a video of test. That would be best because I could post the video and people could see the speed directly.

    I never did get around to running the re-test. But I did have the ~80 files of the test images.

    Much later I found that by looking for the EXIF info from the DNG file using Corel Paintshop Pro X7, I could read the file time down to seconds.

    The composition was high contrast illuminated flower with white petals against a background of trees, many of which were in shadow. My first set was done with EV = +0, which was not a terrible choice. But for my second set I decided that I should expose for the background in order to give the auto-focus a better chance. I can justify this choice because there are certainly situations when the main subject is in shadow and lightening the images is correct. Thinking about this later, maybe I should have adjusted the exposure downward for the flower petals, because they were a "real" point of interest and not just an imaginary possibility.

    I do not know if the camera can be set to use the "touch" to adjust both the focus and the exposure together. I think that that would be the best solution. It might be possible. I have not gotten that far yet.

    Still, that does inadvertently turn this into a "dynamic range test" and I did find out a bit about this camera and its sensor.

    NOTE: No "highlight recovery" and no "noise reduction" were used in the initial images, so these are "worst case" in those regard. The "P9030007-2" image was re-converted with an extra correction to the exposure which can be considered an attempt at "highlight recovery".

    Unfortunately, the "1640" size detail crops turned out to be too big, and I had to compress them beyond the minimum, so more detail has been lost. If the file name ends in "C2" it means that I used compression level 2 which is the next step down from "C1" which is minimum compression. "C4" is two more levels down. I might try to re-do them again someday, but it might take me a while.

    [Uploaded 2018-01-13] Correction Files:
    I have uploaded new "Detail" crop files which are 1200 x 900 and saved as JPEG files with "C1" minimum compression. I will remove the previously uploaded "1640" files later.


    "P9030006 -1" [from DNG]
    Temperature 5260
    Tint 14

    Partial EXIF:
    ASDK-00129
    FlashPix version 01.00
    Date and time Sept 3, 2017 17:17:19
    Image width 5200
    Image height 3902
    Pixel height 3888
    Pixel width 5184
    Component config YCbCr
    Color space sRGB
    Exposure "Normal program"
    Scene capture "Standard"
    Exposure bias 0.00 ev
    Exposure time 1/640 sec.
    F number f/3.9
    Max aperture f/1.8
    Focal length 43.0
    ISO speed 200
    Metering mode Center weighted average
    Gain control Low gain up

    "P9030006 -1-Detail-Crop02-C1.jpg"
    [Uploaded 2018-01-13]
    Crop Starting at "0,2100"
    - cropped to 1200 x 900 and saved with minimum compression to retain detail.


    "P9030007-1"
    Temperature 5416
    Tint 19

    Partial EXIF:
    ASDK-00129
    FlashPix version 01.00
    Date and time Sept 3, 2017 17:17:21
    Image width 5200
    Image height 3902
    Pixel height 3888
    Pixel width 5184
    Component config YCbCr
    Color space sRGB
    Exposure "Normal program"
    Scene capture "Standard"
    Exposure bias 0.00 ev
    Exposure time 1/640 sec.
    F number f/3.9
    Max aperture f/1.8
    Focal length 43.0
    ISO speed 200
    Metering mode Center weighted average
    Gain control Low gain up

    "P9030007 -1-Detail-Crop02-C1.jpg"
    [Uploaded 2018-01-13]
    Crop Starting at "2000,1400"
    - cropped to 1200 x 900 and saved with minimum compression to retain detail.


    "P9030007-2"
    Brightness -1.0
    Temperature 5416
    Tint 19

    SmartFix
    Overall 15 [Recommended 28]
    Shadows -30 [Recommended 0]
    Highlights -15 [Recommended 10]
    Sat 16 [Recommended 0]
    Focus 0 [Recommended 42] *** Lens sharp test
    White Balance OFF
    Black 10 [Recommended 10]
    White 0 [Recommended 0]


    Attached Files:

    Last edited: Jan 13, 2018 at 8:16 PM
