Barrel Distortion?

Discussion in 'Beyond the Basics' started by digital flower, Dec 16, 2005.

  1. digital flower

    digital flower No longer a newbie, moving up!

    Joined:
    Oct 18, 2005
    Messages:
    1,409
    Likes Received:
    36
    Location:
    CT
    First let me say think this photo is cr@p. I have been reading up on barrel distortion and wondered if this was it or did something else happen?

    D70s kit lens @ 18mm

    [​IMG]

  2. Big Mike

    Big Mike I am Big, I am Mike Staff Member Supporting Member

    Joined:
    Dec 16, 2003
    Messages:
    33,822
    Likes Received:
    1,811
    Location:
    Edmonton
    Can others edit my Photos:
    Photos NOT OK to edit
    Looks like barrel distortion to me.

    This one should be fairly easy to fix in photoshop though.

  3. crawdaddio

    crawdaddio TPF Noob!

    Joined:
    Dec 5, 2005
    Messages:
    1,157
    Likes Received:
    14
    Location:
    Central IL
    What's barrel distortion? Is it shown here by the bend in the flagpole? Noob here......

  4. Big Mike

    Big Mike I am Big, I am Mike Staff Member Supporting Member

    Joined:
    Dec 16, 2003
    Messages:
    33,822
    Likes Received:
    1,811
    Location:
    Edmonton
    Can others edit my Photos:
    Photos NOT OK to edit
    Well I don't know if this is exactly barrel distortion or perspective distortion or a bit of both.

    It's not just the flag pole....but the building also. You can see how things that should be parallel (pole & building) are pointing toward each other.

  5. saulmr

    saulmr TPF Noob!

    Joined:
    Aug 18, 2005
    Messages:
    264
    Likes Received:
    4
    Location:
    Juarez, Mexico
    And how do you go about fixing that on Photoshop?

    I have a cheap sony digicam I use for painting listings on eBay and I get that distorsion if I get too close. I makes for very interesting and fun closeups on friends!

  6. Big Mike

    Big Mike I am Big, I am Mike Staff Member Supporting Member

    Joined:
    Dec 16, 2003
    Messages:
    33,822
    Likes Received:
    1,811
    Location:
    Edmonton
    Can others edit my Photos:
    Photos NOT OK to edit
    Off the top of my head...ctrl-A (select all), then under edit, chose transform...skew or perspective.

    You can then stretch the corners out until it looks better. Then you may have to crop.

  7. FuddyDuddy

    FuddyDuddy TPF Noob!

    Joined:
    Jun 13, 2005
    Messages:
    73
    Likes Received:
    0
    Hello

    It looks mostly like converging verticals which you get when the camera is not level (ie pointing upwards).

    Barrel distortion is something completely different where things towards the edge of the frame appear to bend outwards in the shape of a barrel.

    Fuddy

  8. Mitica100

    Mitica100 Moderator Staff Member Supporting Member

    Joined:
    Nov 11, 2003
    Messages:
    9,746
    Likes Received:
    42
    Location:
    Ahwatukee, AZ
    Can others edit my Photos:
    Photos NOT OK to edit
    FuddyDuddy is absolutely right. This has been shot with a Wide Angle lens and the camera was not level. However, there is some minimal barrel distortion, visible on the flagpole. It's almost straight from top to bottom but there is a slight deviation in the middle. Place a sheet of paper on the picture, connecting the top with the bottom of the pole and you'll see it.

  9. AIRIC

    AIRIC TPF Noob!

    Joined:
    Jul 27, 2004
    Messages:
    4,801
    Likes Received:
    83
    Location:
    Brooklin, Ontario, Canuckia
    Can others edit my Photos:
    Photos NOT OK to edit
    At least I can say I learned something today. DFP I hope you don't mind but I gave it a try with your image. I only had a few minutes so it is not perfect but at least now I know how it is done.

    [​IMG]

    Eric

  10. digital flower

    digital flower No longer a newbie, moving up!

    Joined:
    Oct 18, 2005
    Messages:
    1,409
    Likes Received:
    36
    Location:
    CT
    Airic, no problem and nice job. I'll have to try that myself.

    Thanks to everybody who replied. I had a feeling the distortion was something I was doing :wink:

  11. Matty-Bass

    Matty-Bass TPF Noob!

    Joined:
    May 13, 2005
    Messages:
    685
    Likes Received:
    20
    Location:
    Edmonton, AB
    Can others edit my Photos:
    Photos NOT OK to edit
    Looks pretty barrel distorted to me.. but I'm me :er: ;)

    Nonetheless it's a nice shot, interesting shot. :D

  12. BernieSC

    BernieSC TPF Noob!

    Joined:
    Jul 3, 2004
    Messages:
    270
    Likes Received:
    0
    Location:
    South Carolina
    Someone was talking about tilt shift lenses in another post. Thats how tilt and shift lenses correct things like that. Personally when I shoot with a super wide angle lens I like that effect. But if you want to avoid it you would have to shoot at a more paralelle angle straight on. Or use a tilt shift lens.
