Help with Macro lens DOF

Discussion in 'Beyond the Basics' started by Kethaneni, Aug 17, 2009.

  1. Kethaneni

    Kethaneni TPF Noob!

    Joined:
    Sep 9, 2008
    Messages:
    226
    Likes Received:
    0
    Location:
    South riding,VA
    Can others edit my Photos:
    Photos NOT OK to edit
    I am only able to get a very thin frame in sharp focus with my Sigma Macro lens on my D60. I can either get the eyes of the insects in focus or the body and the same with flowers, either I get the petals or the core. Am I doing anything wrong? Any help in this regard would be greatly appreciated.

  2. Josh66

    Josh66 Been spending a lot of time on here!

    Joined:
    Oct 31, 2007
    Messages:
    14,604
    Likes Received:
    1,236
    Location:
    Cedar Hill, Texas
    Can others edit my Photos:
    Photos NOT OK to edit
    No, that's pretty much normal...

    What aperture are you using? Stopping down will help, but even then - it's still going to be pretty thin.

    If you can get the subject more parallel to the film plane, that will help too.

  3. Hardrock

    Hardrock TPF Noob!

    Joined:
    Apr 8, 2009
    Messages:
    1,173
    Likes Received:
    36
    Location:
    Dallas
    Can others edit my Photos:
    Photos NOT OK to edit
    Or a small aperature like 22f and a flash.

  4. djacobox372

    djacobox372 No longer a newbie, moving up!

    Joined:
    May 4, 2008
    Messages:
    2,925
    Likes Received:
    129
    Location:
    Seattle, WA
    Can others edit my Photos:
    Photos NOT OK to edit
    This is why you see macro setups with two powerful flashes... you need to shoot at a very small aperture.

  5. Big Mike

    Big Mike I am Big, I am Mike Staff Member Supporting Member

    Joined:
    Dec 16, 2003
    Messages:
    33,822
    Likes Received:
    1,811
    Location:
    Edmonton
    Can others edit my Photos:
    Photos NOT OK to edit
    Yup...the DOF gets thin as you get closer to your subject...and at Macro distances, it's razor thin. The way to increase your DOF is to 'stop down' the lens (use a smaller aperture). Of course, as you stop down the lens, you need to either increase the exposure time (probably requiring a tripod) or you need to add more light (flash etc).

  6. tirediron

    tirediron Watch the Birdy! Staff Member Supporting Member

    Joined:
    Jul 8, 2005
    Messages:
    37,416
    Likes Received:
    10,678
    Location:
    Victoria, BC
    Can others edit my Photos:
    Photos OK to edit
    Try plugging different numbers into this on-line depth-of-field calculator. It will help you get a better understanding of just how little room you have to work with, even at the smallest apertures.

  7. Overread

    Overread has a hat around here somewhere Staff Member Supporting Member

    Joined:
    May 1, 2008
    Messages:
    23,103
    Likes Received:
    3,767
    Location:
    UK - England
    Can others edit my Photos:
    Photos OK to edit
    Sort of true - you do want to shoot with the smaller apertures (bigger f numbers) to get as much depth of field as you can into the shot. However most macro shooters consider f16 to be the smallest they will go, with many sticking to f13 as a standard smallest size. This is because at around 16 Diffraction will start to take place, its not too bad (in most lenses) at f16, but go smaller (Say to f22) and it will start to make a noticable difference by giving you softer images.

    Actually macro flashes don't have to have that much power - since they are often very close to the subject - many ringflashes and twinlight setups are not that high in guide numbers (compared to say a 580EX speedlite) but they are enough for lighting many macro scenes.
    Flash is an important consideration for macro if you intend to shoot without a tripod, or if your shooting highly mobile insects (where subject movement makes a tripod impractical most times).

  8. Hardrock

    Hardrock TPF Noob!

    Joined:
    Apr 8, 2009
    Messages:
    1,173
    Likes Received:
    36
    Location:
    Dallas
    Can others edit my Photos:
    Photos NOT OK to edit

    Interesting I will try f16 or f13 with my flash. Thanks Overread!

  9. JerryPH

    JerryPH No longer a newbie, moving up!

    Joined:
    Oct 14, 2007
    Messages:
    6,111
    Likes Received:
    15
    Location:
    Montreal, QC, Canada
    Can others edit my Photos:
    Photos NOT OK to edit
    F/11-F/13 seems to be the sweet spot for sharpness with my Sigma 105mm F/2.8 macro.

  10. Kethaneni

    Kethaneni TPF Noob!

    Joined:
    Sep 9, 2008
    Messages:
    226
    Likes Received:
    0
    Location:
    South riding,VA
    Can others edit my Photos:
    Photos NOT OK to edit
    Thanks everyone, I feel a lot better now:peacesign: (worried that I suck at macro). It is really very hard to take macro pictures (especially of bugs) with a tripod, but will try next time.
    Thanks again for all your help.

  11. Phranquey

    Phranquey TPF Noob!

    Joined:
    Feb 16, 2008
    Messages:
    1,527
    Likes Received:
    11
    Location:
    Dayton, OH
    Can others edit my Photos:
    Photos NOT OK to edit
    Phhhhtttttttt........:greenpbl: :lol:

    DOF is definitely also a function of distance. The closer you get, the thinner your DOF is going to get, even stopping down. The following 3 pics were taken at successively closer distances AND gradually stopped down.

    f/40...taken from a few feet away.
    [​IMG]


    f/43
    [​IMG]

    f/45
    [​IMG]

  12. Garbz

    Garbz No longer a newbie, moving up!

    Joined:
    Oct 26, 2003
    Messages:
    9,713
    Likes Received:
    203
    Location:
    Brisbane, Australia
    Can others edit my Photos:
    Photos NOT OK to edit
    Very close, but diffraction is a function of primarily sensor size, as f/22 on two different 105mm lenses would produce the same diffraction because of the same aperture.

    A lens that you say shouldn't go above f/16 (I say f/13 myself) could quite easily be taken a stop higher on an FX camera before diffraction plays the same role in reduced sharpness.
