Pringles Pinhole (sort of..)

Discussion in 'Alternative Techniques & Photo Gallery' started by essjayyell, Jan 19, 2006.

  1. essjayyell

    essjayyell TPF Noob!

    Joined:
    Nov 2, 2004
    Messages:
    216
    Likes Received:
    1
    Location:
    Newcastle, Australia
    I cut a pringles tube about 1/4 of the way up from the bottom, then put the lid on the open end of the smaller piece. I taped this smaller piece to the end of the longer piece so the lid is basically inside the tube, about 1/4 of the way up from the bottom. I poked a small hole in the bottom of the tube.

    The lid is supposed to act as a kind of screen which the image is projected onto, but it didnt quite work out that way for me. Everything is being projected onto the inside of the tube. I stuck the lens of my camera into the tube, pointed it at various things and took some photos.

    Here's what I ended up with. I thought it looked pretty interesting.

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

  2. df3photo

    df3photo TPF Noob!

    Joined:
    Dec 31, 2004
    Messages:
    629
    Likes Received:
    3
    Location:
    Erie Pennsylvania
    Can others edit my Photos:
    Photos NOT OK to edit
    Thats interesting... I wonder what went wrong... kinda neat that it projected on the sides... now it you had it on the screen and the sides that might be neat...
    good luck figuring it out... sounds like something i may have to try....

  3. woodsac

    woodsac TPF Noob!

    Joined:
    Jul 14, 2005
    Messages:
    5,712
    Likes Received:
    260
    Location:
    In a black hole
    Can others edit my Photos:
    Photos NOT OK to edit
    I still like the effect.

    I read about this technique somewhere. I think they lined the inside of the can with black paper. It forced all the light to project at the end, where you wanted it. Might be worth a try before you toss it?

  4. essjayyell

    essjayyell TPF Noob!

    Joined:
    Nov 2, 2004
    Messages:
    216
    Likes Received:
    1
    Location:
    Newcastle, Australia
    I just sprayed the inside with matt black paint. It made it a lot easier to see the image but it's still being projected onto the sides. it might have something to do with the little circle/bump thing on the centre of the lid itself.

    The image on the screen is a bit clearer in these-

    [​IMG]

    [​IMG]

    [​IMG]

    I might make one out of a square box and see how it goes. I need to get a polaroid back so i can do it properly

  5. LaFoto

    LaFoto Just Corinna in real life Staff Member Supporting Member

    Joined:
    Feb 1, 2004
    Messages:
    34,814
    Likes Received:
    814
    Location:
    Lower Saxony, Germany
    Can others edit my Photos:
    Photos NOT OK to edit
    Even though your experiment might not quite have come out in the way you had wanted it to come out, I still am all fascinated by the effect you achieved, the "see-through" Pringles tube... it really gives the impression as if the wall of the tube was a gauze of sorts, while in fact what we see is a projection! Waaaaayyyyyy cool effect!

  6. essjayyell

    essjayyell TPF Noob!

    Joined:
    Nov 2, 2004
    Messages:
    216
    Likes Received:
    1
    Location:
    Newcastle, Australia
    Thanks! I'm happy how it turned out, even if it wasn't what I was expecting.

    Here are some photos of the thing

    I also wrapped it in black tape, just to be sure that it was completely dark inside the tube.

    [​IMG]

    [​IMG]

    [​IMG]

  7. terri

    terri Administrator Staff Member Supporting Member

    Joined:
    Sep 2, 2003
    Messages:
    25,348
    Likes Received:
    2,093
    Location:
    In the mental ward of this forum
    Can others edit my Photos:
    Photos NOT OK to edit
    Awesome! :D I can't wait to see the next round of images from this.

  8. Rob

    Rob TPF Noob!

    Joined:
    Jan 29, 2005
    Messages:
    6,217
    Likes Received:
    134
    Location:
    London
    Yeah - what Terri said! I wonder if there's a clever way of sharpening that projection up a bit... hmm... might have to try it!

    Rob

  9. markc

    markc TPF Noob!

    Joined:
    Mar 8, 2004
    Messages:
    4,237
    Likes Received:
    6
    Location:
    Rochester, NY Velocity: Unknown
    Can others edit my Photos:
    Photos NOT OK to edit
    You are getting that result because of the size of the hole. The bigger the hole, the longer the focus length. A big hole pushes the film plane way back, making the image circle rather big. In your case, it's so big that it's washing onto the sides of the canister.

    A lot of the pinhole cameras I'm familiar with use thin brass or aluminum sheet that a very small hole is either tapped or drilled through using the tip of a small needle or very small drill bit.

    For the canister pihole cameras, I usually see a brass pinhole taped to the curved side, and the film is held opposite. The end is just for access.

    Google has some great links.

  10. ChopstickHero

    ChopstickHero TPF Noob!

    Joined:
    Jan 17, 2006
    Messages:
    159
    Likes Received:
    2
    Location:
    Redlands, CA
    interesting effects....

  11. Fate

    Fate TPF Noob!

    Joined:
    Jan 8, 2006
    Messages:
    1,685
    Likes Received:
    67
    Location:
    England - Worcestershire
    Can others edit my Photos:
    Photos NOT OK to edit
    Once you pop, you just cant stop :D sorry.... i may give that a go this weekend... + it means i can eat a whole thing of pringals for a reason other than being a slob :D

  12. essjayyell

    essjayyell TPF Noob!

    Joined:
    Nov 2, 2004
    Messages:
    216
    Likes Received:
    1
    Location:
    Newcastle, Australia
    Thanks everyone.

    Markc- thanks for the tip, I thought it might have something to do with the size of the hole. It is fairly big.
