Help with D7100 Moving Focus Point Please????

Ratings

TPF Noob!
Joined
Jul 17, 2013
Messages
3
Reaction score
0
I have spent hours alone with my new D7100 and with a professional photographer who shoots with Nikons. We cannot for the life of us figure this ONE Question out. How do you MOVE THE FOCUS POINT (Focal Point) without being in Manual Focus Mode? We can do it without a problem on his Nikon (I think it was a D90). Yes we've tried Page 75 of the manual. It does not work.

I will further clarify: If we put the camera in Manual Focus, it allows us to move the focus point around both while viewing the Monitor screen in the INFO mode and while looking in to the camera viewfinder. We CAN see the highlighted focal point and move it around with the d-pad.

But we cannot do this in the Auto-Focus mode. And, YES WE ARE in AF-S (single servo auto-focus).

I would be so incredibly grateful for help in resolving this incredibly challenging issue.

I have searched the manual high and low and cannot find the solution. I have even contacted Nikon but all they did was refer me to page 75!

Thank you!
Ratings


Mach0

TPF Supporters
Supporting Member
Joined
Oct 16, 2011
Messages
2,616
Reaction score
432
Location
203
Can others edit my Photos
Photos OK to edit
I don't have the d7100 but you need to check what focus mode you are in. Single point etc. make sure your lock isn't on. On the back of the camera should be a switch with and L for lock


SCraig

Been spending a lot of time on here!
Joined
Nov 12, 2011
Messages
6,474
Reaction score
2,450
Location
Nashville, TN
Website
sc-photo-tn.com
Can others edit my Photos
Photos NOT OK to edit
IT doesn't matter whether it's in AF-S or AF-C you can move the focus point in either mode. I do it frequently on my D7000. You will have to disable that focus tracking stuff though. Change the Autofocus Area Mode to Single-point AF (which is NOT the same as AF-S mode).

Also, as Mach0 said make sure that the focus point lock isn't on.


greybeard

Been spending a lot of time on here!
Joined
Dec 30, 2011
Messages
4,161
Reaction score
1,277
Location
WV
Can others edit my Photos
Photos OK to edit
Make sure the focus point lock is not engaged, little lever on the back. This might be the problem.


Tailgunner

No longer a newbie, moving up!
Joined
May 2, 2013
Messages
1,850
Reaction score
280
Location
Dallas TX
Can others edit my Photos
Photos NOT OK to edit
First make sure the focal point is unlocked. You do this by moving the lever on the D button from "L" to the "Dot." Once unlocked, you can use the Direction button to move the focus point.

If your D7100 is set to 11pt or 51pt focal points etc and in Auto focus, you will need to switch to a single focus point. Just hold the center button on the AF/F lever on the bottom left of body with one hand, and use the F-Stop button to switch from Auto to 5 in the view finder with the other hand.

OP
R

Ratings

TPF Noob!
Joined
Jul 17, 2013
Messages
3
Reaction score
0
Thank you Greybeard, Scraig & Mach0.. thank you soooooo much!!!! I did it. I figured it out with your help. FYI - I had single servo AF-S. I had the Unlock position and focus tracking Off. What I couldn't figure out if anyone else is reading this, is this: When you depress the Focus Mode Selector (M or AF), you can select AF-C, AF-S and AF-A by turning the Main Command Dial on the Back of the camera BUT IF YOU TURN the Sub Command Dial on the front of the camera when you depress the Focus Mode Selector, you can get the SINGLE POINT!!!! Only then can you move the Focus Point. Thank you all so much!!! Even Nikon sent me to page 75 which was not the answer! The simple answer is that the camera must be in Single Point Auto Focus Area Mode!

OP
R

Ratings

TPF Noob!
Joined
Jul 17, 2013
Messages
3
Reaction score
0
And thank you Tailgunner!!! I got there before I read your post but you are SPOT ON!!!


LizzyBell

TPF Noob!
Joined
Mar 17, 2014
Messages
1
Reaction score
0
Location
Sydney, Australia
Can others edit my Photos
Photos NOT OK to edit
First make sure the focal point is unlocked. You do this by moving the lever on the D button from "L" to the "Dot." Once unlocked, you can use the Direction button to move the focus point.

If your D7100 is set to 11pt or 51pt focal points etc and in Auto focus, you will need to switch to a single focus point. Just hold the center button on the AF/F lever on the bottom left of body with one hand, and use the F-Stop button to switch from Auto to 5 in the view finder with the other hand.


Thank you everyone. I had the same issue and was becoming very frustrated at being referred back to page 75. You have helped me solve this also!! ��


Ginger8

TPF Noob!
Joined
Mar 13, 2014
Messages
1
Reaction score
0
Location
Philly PA
Can others edit my Photos
Photos NOT OK to edit
Thank you Greybeard, Scraig & Mach0.. thank you soooooo much!!!! I did it. I figured it out with your help. FYI - I had single servo AF-S. I had the Unlock position and focus tracking Off. What I couldn't figure out if anyone else is reading this, is this: When you depress the Focus Mode Selector (M or AF), you can select AF-C, AF-S and AF-A by turning the Main Command Dial on the Back of the camera BUT IF YOU TURN the Sub Command Dial on the front of the camera when you depress the Focus Mode Selector, you can get the SINGLE POINT!!!! Only then can you move the Focus Point. Thank you all so much!!! Even Nikon sent me to page 75 which was not the answer! The simple answer is that the camera must be in Single Point Auto Focus Area Mode!
Yes, thanks to all...including the person who asked. I have been battling with this since I got the camera & it didn't seem to have a solution anywhere, least of all the manual. Love Nikon - not so impressed with their manuals! Anyway, I tried it & it works for me
as well!

$Chickadee with sunflower seed 3-10-14.jpg$Blue Jay with peanut 3-19-14.jpg


MadeMawa

TPF Noob!
Joined
Jun 29, 2014
Messages
1
Reaction score
0
Location
Indonesia
Can others edit my Photos
Photos NOT OK to edit
Hi there,
I am using D7100, just got it yesterday. First I got confuse with this as well. But finally I found it...
1. You need to twist the ring at OK button from L to dot (.)
2. Change the focusing area from wide to single dot by pressing the focus button and thumb scroll.
3. Change the focus type from Auto to other type by pressing button at AF/M ring. At same time use front scroll (right fingertip) to change the focus type.
The AF/M button located at left fingertip if you hold the camera (ready shot position). left side of the lens.
4. Move your desire location of focus by using 4ways button.

Good Luck guys.
Mawa - Bali, Indonesia.


TonyWhats

TPF Noob!
Joined
Jul 14, 2015
Messages
1
Reaction score
0
Can others edit my Photos
Photos OK to edit
Thanks for the help with this issue. Took me a while but I got it, and the simplest thing was I did not realize the 4 way button was how you navigate through the focal points!

Hi there,
I am using D7100, just got it yesterday. First I got confuse with this as well. But finally I found it...
1. You need to twist the ring at OK button from L to dot (.)
2. Change the focusing area from wide to single dot by pressing the focus button and thumb scroll.
3. Change the focus type from Auto to other type by pressing button at AF/M ring. At same time use front scroll (right fingertip) to change the focus type.
The AF/M button located at left fingertip if you hold the camera (ready shot position). left side of the lens.
4. Move your desire location of focus by using 4ways button.

Good Luck guys.
Mawa - Bali, Indonesia.
