Some HIgh Speed shots with the new HiVis Sound Trigger. C&C welcome

Stradawhovious

Been spending a lot of time on here!
Joined
Nov 8, 2010
Messages
3,241
Reaction score
911
Location
Minneapolis, MN
Can others edit my Photos
Photos OK to edit
Hey folks, got he sound trigger working (finally) and decided to take it for a test run. I learned quite a bit today, and feel like sharing...... because I'm just that Kind of a guy.

The first couple of shots were lit by a Nikon SB-27, which has a minimum power setting of 1/16. This isn't low enough power as evidenced by the ghost image of the crayon in the first, and the substantial motion blur of the second. The reason the minimum setting is important, is because the lower power the flash goes off, the shorter the duration of time the image gets exposed. This is key for freezing this type of action. Don't bother to C&C the first two, they are just for example purposes.

1.


2.



These next photos were taken with a Nikon SB-600 which has a minimum power setting of 1/64 which works out to about a 1/26,000th of a second. As you can clearly see, it is much more effective at freezing motion. With the egg shots, the sound trigger's microphone was moved only a half inch back for each of three eggs. You can see the diference it made in timing. I ws amazed that only a half inch o movement would translate to that much of a difference.

3.


4.


5.


6.


These were all kinds of fun to take, but not so much fun to clean up. I'm all ears for criticisms and suggestions, especially if you have had some experience with High Speed photography before. My next move is to try to find a flash with a much lower power setting, and in lieu of that, find more fun and unique things to do with my new toy.

Nice! I think I'm going to be building one of these soon.

The yongnuo yn560 goes down to 1/128. However, I don't know the duration at that power level.

The yongnuo yn560 goes down to 1/128. However, I don't know the duration at that power level.

It seems to be pretty much the same as the 1/64th power of the SB-600. Won't stop me from buying one to test it though, I suppose. They're cheap enough.

I must say, egg is a real pain in the ass to clean out of your camera. :lol:

How did you determine the 1/26k duration figure for the sb600 @ 1/64? Is it published online at a reputable site? Do you know how the measurement is performed? Just curious...

How did you determine the 1/26k duration figure for the sb600 @ 1/64? Is it published online at a reputable site? Do you know how the measurement is performed? Just curious...
Manufacturer's spec. Could be wildly off. Would be nice to determine for reals, but i dont have the means.
