Guys I wanted to take the time to post a methods of mine while processing HDR. I have been asked by many folks what my method is and I wanted to share with you all that are new to HDR.

This is a tutorial for both very realistic and then a little more grunge/painterly and last using third party filters to make your image POP

The first two are only Photomatix and Photoshop

This will be a very long post sorry but hope you will find this informative. The image is not the best image but it should do.

First grab your images and open with photmatix


make sure you select 32bit box. You will use this for later



Once you have gotten to the point where it shows you your first image click save and save it as original hdr





Now select tone map and start using your sliders.

here is mine for this image



process the image and save as normal



drag the orginal hdr onto photomatix icon


now drag your saturation higher and white slider


process and save as vivid



drag the original hdr onto photomatix icon


drag your saturation all the way down to the left and white and black sliders to the right


process and save as shadow map.



open all three in photoshop


select all the shadow map image and copy and paste over your vivid.


now change your opacity to about 30% deepening on what you want.


select all on your normal image and cop and paste it over the vivid and shadow map.


Now make it a vector mask in your layers window and use your paint bucket and paint it black


Now use your paintbrush using white and paint areas that are to black and lost detail from your shadow map.


Flatten image.


duplicate image and select auto color. Change as you see fit.


Now create a levels layer and adjust as you see fit for your image and flatten.


done Final image

-----------------------------------------------------------------------------------------------------------------------------------------------


Grungier more processing HDR look


Start off with your original 32bit hdr file



Now adjust sliders as you see fit for the more HDR grunge look



here are mine



process and save as normal



drag your original 32bit back into photomatix and adjust the saturation and whites and both highlight and shadows


process and save as vivid



drag your original 32bit back into photomatix and adjust the bring saturation all the way to the left and whites blacks all the way to the right and highlights and shadows to the left


process and save as shadow map




select all the shadow map image and copy and paiste over your vivid.


now change your opacity to about 30% deepening on what you want.


select all on your normal image and cop and paste it over the vivid and shadow map at 30%.


flaten


duplicate layer


auto color 50% is what I went with


create levels layer adjust midtown


flatten


duplicate layer


add vibrance layer and adjust both vibrance and saturation.


merge layer

add selective color layer and adjust colors to your choice.


add some sharpening or unsharp mask


done Final Image







If you have Nik Color effex or Topaz Adjust/ Denoise you can take your image further


I have both but prefer Nik Color Effex


I would not add a detail extractor or bleach bypass or combo of both.


Then I would use topaz denies to remove some noise


Then I would adjust opacity if I felt it was to soft


Next I would add layer and use high pass filter


Set blending mode to linear light and opacity to 30-50%


Flatten and done.



This is just one way I do HDR. I sometimes will process 2-4 photos from photomatix and then blend in photoshop. I sometimes do not create normal,vivid and shadow map because I have filters that can do just about the same thing and takes less time note: (when using filters that does this for me it will give a different effect no so realistic)
When I do HDR I usually have a vision when I shoot the picture but in many cases when I am processing I just flow with my gut feeling and if I am listening to music that tends to change my processing methods..Threre are many ways to process and this is not the Holy Grail of how to but, a simple way to get a realistic HDR image and or more grunge without over cooking your image from photomatix.

Cheers
